Use the Image component to present information in your apps in a vivic way. PocketBlocks supports you adding an image via URL and base64 encoded data.

URL

Drag the Image component onto the canvas or into a Container. Click the Image component, and the Properties tab is displayed on the right. You can set the URL to display an image.

Base64 encoded data


Don't miss the comma at the end of the prefix:


data:image;base64,YOUR_BASE64_ENCODED_IMAGE_DATA

Demo: upload and display an image

One common use case for base64 image display would be combining a File Upload component with an Image component.

Here is JS code that concatenates the prefix with the encoded base64 data of the uploaded file via file1.value[0].

{
  {
  }
}

Set click preview for an image

Toggle Support click preview in the Properties tab to allow users to preview the image in its full size. Hover your mouse over the image, and you see 👁 Preview. Then, you can click to preview.

Set the style of an image

In Properties > Style, change border color and set Border radius in pixels or by percentage.
